16mm2 Ug Power Cable 0.6/1kv Copper Cable with XLPE Insulation Material for Power Stations

Klasifikasi mereka：

Kabel tegangan rendah
membagikan：
Kode QR:
Waktu rilis：

2025-07-03 06:55:48

Pertanyaan Instan

PENDAHULUAN PRODUK

1. Product Overview

This 16mm² UG-type Power Cable is engineered for Power Stations and demanding industrial environments. Featuring Class 2 annealed Copper Conductors per GB/T 3956 and XLPE insulation, the 0.6/1kV rated cable complies with IEC 60502-1 and GB/T 12706.1 standards, making it ideal for critical applications like main power distribution and transformer connections.

2. Technical Specifications

Parameter	Value	Standard
Conductor	16mm² Class 2 copper	GB/T 3956
Insulation	1.4mm XLPE	IEC 60502
Sheath	2.0mm flame-retardant PVC	GB/T 18380
DC Resistance	≤1.15Ω/km (20℃)	GB/T 3048
AC Withstand	3.5kV/5min no breakdown	IEC 60502
Bending Radius	≥12×OD	GB/T 12706

3. Key Advantages

Electrical:
✓ Partial discharge <10pC
✓ Insulation resistance Ki≥3.67 MΩ·km
Mechanical:
✓ Tensile strength≥12.5N/mm²
✓ Passes 100,000 bend cycles
Environmental:
✓ -40℃ cold bend test approved
✓ Chemical Resistance (pH2-12, 30 days)

4. Typical Applications

Power Stations:
→ Main transformer wiring
→ Generator outlet circuits
→ Auxiliary power systems
Industry:
→ Steel plant power supply
→ Petrochemical hazardous areas
→ Mining mobile equipment
